LOADIX : the first autonomous agricultural handling robot

  1. Accueil
  2. Loadix
Biogas with LOADIX

LOADIX : ideal for biogas applications

Designed to repeatedly move bulk organic material between two points, LOADIX is particularly well-suited for biogas plants. The robot is ideal for partially or fully handling material inputs into the biogas incorporator.

The embedded technologies of LOADIX

Vision, Localization, and Navigation
LOADIX's localization and navigation are managed by an RTK GPS, an INS (Inertial Navigation System), odometers, and a Lidar that allows it to perceive its environment. By combining information from these various sensors, LOADIX determines its position with high accuracy. This enables it to move safely within its working environment, including inside agricultural buildings.
Battery
The decision was made to use lithium batteries to allow greater flexibility in usage. These batteries can be charged at any time without damaging their lifespan.
Mobility
LOADIX is equipped with 4-wheel drive and steering, providing it with great movement flexibility. It can cope with potholes, small steps, and slopes of up to 30%.
Handling / Lifting Arm
The handling arm can lift to a maximum height of 4.10 meters and has a lifting capacity of 2 tons. LOADIX is designed compactly, with the arm extending vertically and integrating into the robot’s body in the lowered position.
Safety
A panel of sensors allows LOADIX to detect people, animals, machines, buildings, and any other obstacles in its immediate environment. Any obstacle detection causes the robot to stop immediately, with an emergency brake if necessary. If the obstacle moves out of the robot's detection zone, it will automatically restart and continue its task.
Implement changeover
During the same mission, LOADIX may need to change implement for handling different materials or to adhere to sanitary regulations. This change is done autonomously even for implements with hydraulic functions such as grab buckets or sweepers.
Recharging
LOADIX has its own 32A charging station to which it autonomously moves and connects without human intervention. The robot calculates the optimal time to connect, based on preserving the battery’s lifespan and its mission schedule.
Battery

LOADIX's Autonomy

The autonomy of your LOADIX depends on the length of its routes, the weight it carries, and the number of task repetitions. Generally, a LOADIX can operate autonomously for 2 to 4 hours, allowing it to complete several work sessions in a day with short recharge breaks. It is important to note that LOADIX does not let its battery fully deplete before recharging. Instead, it assesses the optimal time to recharge based on the urgency of the assigned mission and the battery’s charge level. This optimization strategy helps to maintain the battery and extend its lifespan.

With the Manurob software

LOADIX Connect: The App for Real-Time Monitoring of Your LOADIX

LOADIX Connect is a simple and intuitive application that allows you to plan LOADIX's missions and receive useful real-time information. The interactive app sends you notifications when your robot completes a mission or when a potential issue arises.
About LOADIX Connect

Advantages

Autonomous

LOADIX performs its assigned missions autonomously, goes to recharge or change implement when needed, and always selects the fastest route.

Versatile

LOADIX is designed to handle tasks such as loading the digester, sweeping the yards, and soon, feeding livestock.

Easy

To supervise LOADIX, you only need the LOADIX Connect app. Intuitive and user-friendly, it allows you to easily access all the information you need.

Durable

By opting for electric power and its design choices, LOADIX extends the lifespan of its battery and components, making it a more sustainable solution.

Safe

LOADIX is equipped with a Lidar, side sensors, and sensitive edges on its bumpers, ensuring the safety of people in the vicinity.

Up to date

Your LOADIX and the LOADIX Connect application will be updated so that you always benefit from an up-to-date and efficient version.

No worry maintenance

Dedicated service packages will take care of your maintenance needs (with the exception of oil and filter changes), as well as repairs in the event of breakdown, guaranteeing peace of mind.
About maintenance

Professional after sales services

Once your LOADIX has been installed, your authorized dealer will provide 7/7 service for your robot.
About after-sale service

LOADIX implements

Learn more
Multi-purpose skip

Multi-purpose bucket with grabs

Benne de reprise MX Manurob

General Purpose bucket

Requirements for installing LOADIX on your farm

Are you wondering how LOADIX is installed on a farm or biogas unit ? Don’t hesitate to contact us, our advisors are here to help you !

Contact us
  • Private farmyard
  • A clearly defined material handling process
  • Stabilized roads & tracks

The stages for installing a LOADIX :

1
Initial contact

Your operation is compatible with a LOADIX and you'd like to have one on your farm. The first step is to contact us to discuss your needs and your project. We'll answer all your questions.

2
Installation and training

You've decided to adopt a LOADIX on your farm. The ManuRob team will configure your robot and install the necessary equipment (wifi relays, charging station, the ManuRob hub...). Finally, we'll provide you with the training you need to feel at ease with your LOADIX.

3
LOADIX commissioning

Congratulations! Your LOADIX is ready to use. Designate the type of organic material stored at each pre-programmed storage point. Create your rations - you may have different mixes for your biogas unit depending on arrivals or the season. Then set the missions in the agenda for the dates and times that suit you. LOADIX will take care of everything from there on...totally autonomously!

Frequently asked questions

Does Loadix require human intervention?

You only need to set the recipes, materials, and quantities you want to move in the Loadix Connect app and schedule these tasks in Loadix’s calendar. No further intervention is usually required, except for maintenance approximately every 1500 hours.

Does Loadix emit CO2?

During its use, Loadix emits no CO2.

What is the weight of Loadix?

Empty, Loadix weighs 5 tons. When fully loaded, it can weigh up to 7 tons.

Is Loadix noisy ?

An electric motor powers the hydraulic system. When Loadix moves or operates its arm, you will hear its electric motor, but the noise is not strong.

Explore all questions
